This is the operational companion to VK Remote — Self-Hosting the Kanban Backend Before the Cloud Dies. That post explains the architecture and deployment. This one is the day-to-day runbook.

What “Healthy” Looks Like

A healthy VK Remote stack has:

  • Three pods running in the agents namespace: postgres-vk, electric, vk-remote
  • PostgreSQL accepting connections with wal_level=logical
  • ElectricSQL connected to the PG replication stream
  • vk-remote responding on port 8081 with a healthy API
  • The init Job (postgres-vk-init-electric) in Completed state
  • Browser access working at https://vk.cluster.derio.net through Authentik SSO

Observing State

Pod Health

# All pods in the agents namespace
kubectl -n agents get pods -o wide

# Specifically check the three VK components
kubectl -n agents get pods -l 'app in (postgres-vk, electric, vk-remote)'
$ kubectl get pods -n agents -o wide
NAME                              READY   STATUS      RESTARTS   AGE   IP              NODE     NOMINATED NODE   READINESS GATES
electric-6c5f6487d7-prswg         1/1     Running     0          8d    10.244.12.187   mini-1   <none>           <none>
postgres-vk-557b4b6b7-9xvwq       1/1     Running     0          8d    10.244.13.229   mini-2   <none>           <none>
postgres-vk-init-electric-pgqzp   0/1     Completed   0          21h   10.244.12.96    mini-1   <none>           <none>
vk-remote-7949d8bb66-vpgpx        2/2     Running     0          21h   10.244.13.68    mini-2   <none>           <none>

PostgreSQL

# Check PG is running and WAL level
kubectl -n agents exec deploy/postgres-vk -- \
  psql -U remote -d remote -c "SHOW wal_level;"
# Expected: logical

# Check replication slots (ElectricSQL creates one)
kubectl -n agents exec deploy/postgres-vk -- \
  psql -U remote -d remote -c "SELECT slot_name, active FROM pg_replication_slots;"
$ kubectl -n agents exec deploy/postgres-vk -- psql -U remote -d remote -c 'SHOW wal_level;'
 wal_level
-----------
 logical
(1 row)


$ kubectl -n agents exec deploy/postgres-vk -- psql -U remote -d remote -c 'SELECT slot_name, active FROM pg_replication_slots;'
       slot_name       | active
-----------------------+--------
 electric_slot_default | t
(1 row)

# Check the electric role exists
kubectl -n agents exec deploy/postgres-vk -- \
  psql -U remote -d remote -c "SELECT rolname FROM pg_roles WHERE rolname = 'electric';"

ElectricSQL

# ElectricSQL logs — look for "Connected to Postgres" and shape sync activity
kubectl -n agents logs deploy/electric --tail=20

# Check ElectricSQL health
kubectl -n agents exec deploy/vk-remote -- \
  wget -qO- http://electric:3000/v1/health 2>/dev/null || echo "unreachable"

VK Remote API

# Health endpoint (from inside the cluster)
kubectl -n agents exec deploy/vk-remote -- \
  wget -qO- http://localhost:8081/v1/health

# Health endpoint (via Traefik — will redirect through Authentik if not authenticated)
curl -s -o /dev/null -w "%{http_code}" https://vk.cluster.derio.net/v1/health

Init Job Status

# Check if the init job completed
kubectl -n agents get jobs
# Expected: postgres-vk-init-electric — Completions: 1/1

Service Endpoints

# Verify all services have endpoints
kubectl -n agents get endpoints postgres-vk electric vk-remote

Common Operations

Restart VK Remote

kubectl -n agents rollout restart deploy/vk-remote
kubectl -n agents rollout status deploy/vk-remote

Restart PostgreSQL

Since PostgreSQL uses Recreate strategy (RWO PVC), the restart will cause brief downtime for the entire stack:

kubectl -n agents rollout restart deploy/postgres-vk
kubectl -n agents rollout status deploy/postgres-vk

After PG restarts, ElectricSQL will automatically reconnect to the replication stream. No manual intervention needed.

Restart ElectricSQL

kubectl -n agents rollout restart deploy/electric
kubectl -n agents rollout status deploy/electric

Login and Get JWT Token

# Get the local auth password
PASSWORD=$(kubectl -n agents get secret vk-remote-secrets \
  -o jsonpath='{.data.SELF_HOST_LOCAL_AUTH_PASSWORD}' | base64 -d)

# Login (from a pod with network access, or via port-forward)
kubectl -n agents port-forward svc/vk-remote 8081:8081 &
TOKEN=$(curl -s -X POST http://localhost:8081/v1/auth/local/login \
  -H 'Content-Type: application/json' \
  -d "{\"email\":\"admin@localhost\",\"password\":\"$PASSWORD\"}" | jq -r '.token')
echo "Token: $TOKEN"

List Organizations and Projects

# List orgs
curl -s -H "Authorization: Bearer $TOKEN" http://localhost:8081/v1/organizations | jq

# List projects
curl -s -H "Authorization: Bearer $TOKEN" http://localhost:8081/v1/projects | jq

Check PVC Usage

kubectl -n agents exec deploy/postgres-vk -- df -h /var/lib/postgresql/data

Troubleshooting

ElectricSQL Not Syncing

Symptom: The kanban board in the browser doesn’t update in real-time when issues change.

Check: Is ElectricSQL connected to the replication stream?

kubectl -n agents logs deploy/electric --tail=30

If you see connection errors:

  1. Verify the electric PG role exists: kubectl -n agents exec deploy/postgres-vk -- psql -U remote -d remote -c "SELECT rolname FROM pg_roles WHERE rolname = 'electric';"
  2. If the role is missing, delete and re-trigger the init job: kubectl -n agents delete job postgres-vk-init-electric then sync ArgoCD
  3. Restart ElectricSQL: kubectl -n agents rollout restart deploy/electric

Init Job Failed

Symptom: kubectl -n agents get jobs shows postgres-vk-init-electric with failed completions.

Check logs:

kubectl -n agents logs job/postgres-vk-init-electric

Common causes:

  • PostgreSQL wasn’t ready in time — delete the job and let ArgoCD re-create it
  • Password mismatch — verify the ExternalSecret has synced: kubectl -n agents get externalsecret vk-remote-secrets

502 on vk.cluster.derio.net

Symptom: Browser shows 502 Bad Gateway.

Check: Is the vk-remote pod running?

kubectl -n agents get pods -l app=vk-remote
kubectl -n agents logs deploy/vk-remote --tail=30

If the pod is in CrashLoopBackOff, check:

  1. Database connectivity: the SERVER_DATABASE_URL uses variable substitution — if the Secret is missing, the env var resolves to an empty password
  2. Secret sync: kubectl -n agents get externalsecret vk-remote-secrets -o jsonpath='{.status.conditions}'

Cannot Login via API

Symptom: POST to /v1/auth/local/login returns 401 or 500.

Check:

  1. Correct password: kubectl -n agents get secret vk-remote-secrets -o jsonpath='{.data.SELF_HOST_LOCAL_AUTH_PASSWORD}' | base64 -d
  2. Correct email: must be admin@localhost
  3. Database accessible: the login endpoint writes to PostgreSQL

Authentik SSO Not Working

Symptom: Browser redirects to Authentik but loops or returns 403.

Check: Is the Authentik proxy provider assigned to the embedded outpost?

kubectl exec -n authentik deploy/authentik-server -- python -c "
import os; os.environ.setdefault('DJANGO_SETTINGS_MODULE','authentik.root.settings')
import django; django.setup()
from authentik.outposts.models import Outpost
outpost = Outpost.objects.get(name='authentik Embedded Outpost')
print([p.name for p in outpost.providers.all()])
"

If VK Remote (cluster) is not in the list, assign it:

kubectl exec -n authentik deploy/authentik-server -- python -c "
import os; os.environ.setdefault('DJANGO_SETTINGS_MODULE','authentik.root.settings')
import django; django.setup()
from authentik.providers.proxy.models import ProxyProvider
from authentik.outposts.models import Outpost
outpost = Outpost.objects.get(name='authentik Embedded Outpost')
provider = ProxyProvider.objects.get(name='VK Remote (cluster)')
outpost.providers.add(provider)
print(f'Added {provider.name} to {outpost.name}')
"

ArgoCD Sync

# Check vk-remote app status
argocd app get vk-remote --port-forward --port-forward-namespace argocd

# Force sync if needed
argocd app sync vk-remote --port-forward --port-forward-namespace argocd
