Operating on VK Relay

Operating on VK Relay

This is the operational companion to VK Relay — Tunneling the Browser to a Local Agent Server. That post explains the architecture and deployment. This one is the day-to-day runbook.

What “Healthy” Looks Like

A healthy VK relay setup has:

  • The vk-remote pod running with two containers: vk-remote and relay-server
  • Relay server listening on port 8082
  • The /v1/relay/ path reachable through Traefik at vk.cluster.derio.net
  • The local VK server in the secure-agent-pod connected via WebSocket tunnel
  • Browser paired and able to view workspace data through the remote UI

Observing State

Pod Health

# Verify both containers are running
kubectl -n agents get pods -l app=vk-remote -o wide

# Check container names (should list: vk-remote relay-server)
kubectl -n agents get pods -l app=vk-remote \
  -o jsonpath='{.items[0].spec.containers[*].name}'

Relay Server Logs

# Relay server logs
kubectl -n agents logs deploy/vk-remote -c relay-server --tail=20

# Follow relay logs (useful during pairing or debugging)
kubectl -n agents logs deploy/vk-remote -c relay-server -f

Expected healthy output includes: Relay server listening on 0.0.0.0:8082

Relay Endpoint Reachability

# Test relay endpoint through Traefik (expect 401 — JWT auth required)
curl -s -o /dev/null -w "%{http_code}" https://vk.cluster.derio.net/v1/relay/connect

A 401 means the relay is running and reachable — it’s rejecting the request because there’s no JWT token. A 404 means the IngressRoute isn’t routing correctly. A 502 means the relay container is down.

$ kubectl -n agents get pods -l app=vk-remote -o wide
NAME                         READY   STATUS    RESTARTS   AGE   IP             NODE     NOMINATED NODE   READINESS GATES
vk-remote-7949d8bb66-vpgpx   2/2     Running   0          21h   10.244.13.68   mini-2   <none>           <none>

$ curl -s -o /dev/null -w "relay status: %{http_code}
" https://vk.cluster.derio.net/v1/relay/connect
relay status: 401

Service Ports

# Verify both ports are exposed
kubectl -n agents get svc vk-remote
# Expected: 8081/TCP (http) and 8082/TCP (relay)

Common Operations

Restart the Relay

The relay is a sidecar in the vk-remote pod — restarting the pod restarts both containers:

kubectl -n agents rollout restart deploy/vk-remote
kubectl -n agents rollout status deploy/vk-remote

Re-Pairing

If the browser loses its IndexedDB data (cleared storage, new browser, new device), re-pair:

  1. Port-forward to the local VK server:
    kubectl -n secure-agent-pod port-forward deploy/secure-agent-pod 8081:8081
  2. Open http://localhost:8081 → Settings → Relay Settings → “Generate pairing code”
  3. Open https://vk.cluster.derio.net → Settings → “Pair host” → enter code
  4. Stop the port-forward — the relay handles everything from here

Check Local Server Relay Connection

# Check if the local VK server is connected to the relay
kubectl -n secure-agent-pod logs deploy/secure-agent-pod -c kali --tail=50 | grep -i relay

If the local server isn’t connecting, verify the env var is set:

kubectl -n secure-agent-pod exec deploy/secure-agent-pod -c kali -- \
  env | grep VK_SHARED_RELAY
# Expected: VK_SHARED_RELAY_API_BASE=https://vk.cluster.derio.net

Troubleshooting

Workspace Data Not Loading in Remote UI

Symptom: The remote UI at vk.cluster.derio.net shows workspaces but clicking into one shows no repos, sessions, or diffs.

Check: Is the relay tunnel established?

# Relay logs — look for active tunnel connections
kubectl -n agents logs deploy/vk-remote -c relay-server --tail=30

If no tunnel connections appear, the local VK server isn’t connecting. Check:

  1. The secure-agent-pod is running
  2. VK_SHARED_RELAY_API_BASE env var is set
  3. Cilium egress policy allows outbound to vk.cluster.derio.net

502 on Relay Path

Symptom: curl https://vk.cluster.derio.net/v1/relay/connect returns 502.

Cause: The relay-server container is not running or not ready.

# Check container status
kubectl -n agents describe pod -l app=vk-remote | grep -A5 relay-server

# Check for crash loops
kubectl -n agents logs deploy/vk-remote -c relay-server --previous

Pairing Code Rejected

Symptom: Entering the 6-digit pairing code in the remote UI fails.

Causes:

  • Code expired (codes are short-lived — generate a fresh one)
  • Browser and local server not on the same relay (verify both point to vk.cluster.derio.net)
  • SPAKE2 mismatch — regenerate and try again

ArgoCD Sync

# Check vk-remote app status
argocd app get vk-remote --port-forward --port-forward-namespace argocd

# Force sync if needed
argocd app sync vk-remote --port-forward --port-forward-namespace argocd
