Operating on In-Cluster Ingress

Companion operations guide for In-Cluster Ingress — Traefik, Wildcard TLS, and a Homepage Dashboard.

Quick Health Check

# Traefik pod status and node placement
kubectl get pods -n traefik-system -o wide

# Homepage pod
kubectl get pods -n homepage -o wide

# ArgoCD app status
kubectl get applications -n argocd traefik traefik-extras homepage

# ACME cert file size (should be >3KB if cert is issued)
kubectl exec -n traefik-system deploy/traefik -- ls -la /data/acme.json

ACME Certificate

Check Certificate Status

# Look for ACME-related log entries
kubectl logs -n traefik-system deploy/traefik | grep -iE "acme|certif|renew"

Healthy output shows Testing certificate renew... followed by Starting provider *acme.Provider with no errors.

Force Certificate Renewal

Delete the ACME storage and restart to force a fresh cert request:

kubectl exec -n traefik-system deploy/traefik -- rm /data/acme.json
kubectl delete pod -n traefik-system -l app.kubernetes.io/name=traefik

Note: the 60-second propagation delay means renewal takes ~90 seconds.

Common ACME Failures

Symptom	Cause	Fix
`permission denied` on acme.json	Missing `fsGroup: 65532` in podSecurityContext	Add top-level `podSecurityContext.fsGroup: 65532` to values
`nonexistent certificate resolver`	acme.json unwritable at startup	Fix permissions, restart pod
`NXDOMAIN looking up TXT`	DNS propagation too fast	Increase `propagation.delayBeforeChecks` (default: 60s)
`NXDOMAIN` persistent	Cloudflare API token invalid	Check `CF_DNS_API_TOKEN` secret in `traefik-system`

Verify TLS From CLI

curl -sI https://argocd.cluster.derio.net 2>&1 | head -5
# Should show HTTP/2 200 or 302 with valid TLS

IngressRoutes

List All Routes

kubectl get ingressroutes -n traefik-system

Add a New IngressRoute

Add the route to apps/traefik/manifests/ingressroutes.yaml
Add to apps/homepage/manifests/configmap-services.yaml
If forward-auth needed:
- Add blueprint entry to apps/authentik-extras/manifests/blueprints-cluster-proxy-providers.yaml
- After deploy, assign provider to outpost (see Authentik section below)

Debug a Route

# Check Traefik logs for a specific route
kubectl logs -n traefik-system deploy/traefik | grep "<hostname>"

# Test from inside the cluster (bypasses Traefik)
kubectl run -it --rm debug --image=busybox -- wget -qO- http://<service>.<namespace>:<port>/

Authentik Forward-Auth

Check Provider Assignment

kubectl exec -n authentik deploy/authentik-server -- python -c "
import os; os.environ.setdefault('DJANGO_SETTINGS_MODULE','authentik.root.settings')
import django; django.setup()
from authentik.outposts.models import Outpost
outpost = Outpost.objects.get(name='authentik Embedded Outpost')
for p in outpost.providers.all():
    print(f'  {p.name}')
print(f'Total: {outpost.providers.count()} providers')
"

Add a New Provider to the Outpost

After the Authentik blueprint creates the provider:

kubectl exec -n authentik deploy/authentik-server -- python -c "
import os; os.environ.setdefault('DJANGO_SETTINGS_MODULE','authentik.root.settings')
import django; django.setup()
from authentik.providers.proxy.models import ProxyProvider
from authentik.outposts.models import Outpost
outpost = Outpost.objects.get(name='authentik Embedded Outpost')
provider = ProxyProvider.objects.get(name='<PROVIDER_NAME>')
outpost.providers.add(provider)
print(f'Added {provider.name} to {outpost.name}')
"

Check Blueprint Status

kubectl exec -n authentik deploy/authentik-server -- python -c "
import os; os.environ.setdefault('DJANGO_SETTINGS_MODULE','authentik.root.settings')
import django; django.setup()
from authentik.blueprints.models import BlueprintInstance
for b in BlueprintInstance.objects.filter(path__contains='proxy'):
    print(f'{b.name} status={b.status}')
"

Force Blueprint Re-Apply

# Restart the worker (blueprints are processed by the worker, not server)
kubectl rollout restart deploy/authentik-worker -n authentik

Common Forward-Auth Failures

Symptom	Cause	Fix
HTTP 404 from Authentik	Provider not assigned to outpost	Run the outpost assignment command above
HTTP 404 after deploy	Blueprint not applied (missing `invalidation_flow`)	Check worker logs for serializer errors
Forward-auth redirect to wrong URL	`AUTHENTIK_HOST` env var wrong	Check `global.env` in `apps/authentik/values.yaml`

Homepage Dashboard

Restart After ConfigMap Change

ArgoCD syncs the ConfigMap, but the Homepage pod needs a restart to pick up changes:

kubectl rollout restart deploy/homepage -n homepage

Add a New Service

Edit apps/homepage/manifests/configmap-services.yaml:

        - ServiceName:
            icon: icon-name    # si-* (Simple Icons) or mdi-* (Material Design)
            href: https://service.cluster.derio.net
            description: One-line description
            siteMonitor: http://service.namespace:port

Use siteMonitor (HTTP health check), not ping (ICMP doesn’t work for ClusterIP).

Check Health From Pod

# Verify Homepage can reach internal services
kubectl exec -n homepage deploy/homepage -- wget -qO- --timeout=3 http://argocd-server.argocd:80 | head -5

Middleware CRDs

List Middlewares

kubectl get middlewares -n traefik-system

Current middlewares:

security-headers — HSTS, X-Frame-Options, CSP
ip-allowlist — RFC 1918 ranges only
authentik-forwardauth — Authentik embedded outpost

Cloudflare DNS Token

The SOPS-encrypted secret is in secrets/traefik-cloudflare-credentials.yaml. To re-apply:

sops --decrypt secrets/traefik-cloudflare-credentials.yaml | kubectl apply -f -
