Operating on Workflow Automation

This is the operational companion to Workflow Automation with n8n. That post explains the architecture and deployment. This one is the day-to-day runbook for checking health, managing the database, adding instances, and troubleshooting.

What “Healthy” Looks Like

A healthy n8n instance has:

The n8n pod running (1/1 Ready) on gpu-1
The PostgreSQL pod running (1/1 Ready) in the same namespace
The LoadBalancer Service showing the assigned external IP
The /healthz endpoint returning 200
Metrics flowing at /metrics

Observing State

Pod Health

# Both pods in one view
kubectl -n n8n-01 get pods

# Detailed pod status (events, conditions)
kubectl -n n8n-01 describe pod -l app.kubernetes.io/name=n8n-01

Service and Networking

# Verify LoadBalancer IP assignment
kubectl -n n8n-01 get svc n8n-01

# Quick health check
curl -s -o /dev/null -w "%{http_code}" http://192.168.55.216:5678/healthz

# Metrics endpoint
curl -s http://192.168.55.216:5678/metrics | head -10

$ kubectl -n n8n-01 get pods
NAME                     READY   STATUS    RESTARTS   AGE
n8n-01-ddb7c789c-xv8mr   1/1     Running   0          21d
n8n-01-postgresql-0      1/1     Running   0          21d

$ kubectl -n n8n-01 get svc n8n-01
NAME     TYPE           CLUSTER-IP      EXTERNAL-IP      PORT(S)          AGE
n8n-01   LoadBalancer   10.102.108.93   192.168.55.216   5678:32466/TCP   21d

$ curl -s -o /dev/null -w "healthz: %{http_code}
" http://192.168.55.216:5678/healthz
healthz: 200

ArgoCD Sync Status

# Both apps at a glance
argocd app get n8n-01 --server 192.168.55.200 --insecure | head -10
argocd app get n8n-01-postgresql --server 192.168.55.200 --insecure | head -10

Logs

# n8n application logs
kubectl -n n8n-01 logs -l app.kubernetes.io/name=n8n-01 -c n8n --tail=50

# PostgreSQL logs
kubectl -n n8n-01 logs -l app.kubernetes.io/name=n8n-01-postgresql --tail=50

Database Operations

Connect to PostgreSQL

# Port-forward to access psql
kubectl -n n8n-01 port-forward svc/n8n-01-postgresql 5432:5432 &

# Connect (password from SOPS secret)
PGPASSWORD=$(sops --decrypt secrets/n8n-01/n8n-01-secrets.yaml | grep "  password:" | head -1 | awk '{print $2}') \
  psql -h localhost -U n8n -d n8n

Check Database Size

SELECT pg_size_pretty(pg_database_size('n8n'));

List Workflow Executions

SELECT id, "workflowId", finished, "startedAt", "stoppedAt", status
FROM execution_entity
ORDER BY "startedAt" DESC
LIMIT 10;

Clean Old Executions

n8n can accumulate execution history. To prune old entries:

DELETE FROM execution_entity
WHERE "startedAt" < NOW() - INTERVAL '30 days'
AND status = 'success';

Adding a New Instance

Follow the duplication guide:

# 1. Copy manifests
cp -r apps/n8n-01 apps/n8n-02
cp -r apps/n8n-01-postgresql apps/n8n-02-postgresql

# 2. Find-replace in all files
find apps/n8n-02 apps/n8n-02-postgresql -type f -exec sed -i '' 's/n8n-01/n8n-02/g' {} +

# 3. Copy Application CRs
for tmpl in ns-n8n-01 n8n-01 n8n-01-postgresql; do
  new=$(echo $tmpl | sed 's/n8n-01/n8n-02/g')
  cp apps/root/templates/${tmpl}.yaml apps/root/templates/${new}.yaml
  sed -i '' 's/n8n-01/n8n-02/g' apps/root/templates/${new}.yaml
done

# 4. Update the IP (pick next available, e.g. 192.168.55.217)
sed -i '' 's/192.168.55.216/192.168.55.217/g' apps/n8n-02/manifests/service.yaml

# 5. Add Authentik proxy provider entries to blueprints-proxy-providers.yaml
# (copy the n8n-01 block, replace n8n-01 → n8n-02, update external_host)

# 6. Create SOPS secret
mkdir -p secrets/n8n-02
# Create secrets/n8n-02/n8n-02-secrets.yaml with new passwords
sops --encrypt --in-place secrets/n8n-02/n8n-02-secrets.yaml

# 7. Apply and push
sops --decrypt secrets/n8n-02/n8n-02-secrets.yaml | kubectl apply -f -
git add apps/n8n-02 apps/n8n-02-postgresql apps/root/templates/*n8n-02* secrets/n8n-02
git commit -m "feat(agents): add n8n-02 instance"
git push

Upgrading n8n

Check the n8n releases for the latest stable version, then update the image tag in the deployment:

# Current version
kubectl -n n8n-01 get deploy n8n-01 -o jsonpath='{.spec.template.spec.containers[0].image}'

# Update (edit the deployment manifest)
# In apps/n8n-01/manifests/deployment.yaml, change:
#   image: docker.io/n8nio/n8n:2.13.4
# To:
#   image: docker.io/n8nio/n8n:<new-version>

# Commit and push — ArgoCD syncs, Recreate strategy replaces the pod

Before upgrading: Check the release notes for breaking changes, especially database migrations. n8n runs migrations automatically on startup.

Restarting

# Restart n8n (Recreate strategy — brief downtime)
kubectl -n n8n-01 rollout restart deployment n8n-01

# Restart PostgreSQL
kubectl -n n8n-01 rollout restart statefulset n8n-01-postgresql

Troubleshooting

Pod Stuck in CreateContainerConfigError

The SOPS secret hasn’t been applied to the namespace. The pod can’t mount the n8n-01-secrets Secret.

# Apply the secret
sops --decrypt secrets/n8n-01/n8n-01-secrets.yaml | kubectl apply -f -

n8n Shows “Secure Cookie” Error

n8n requires TLS for secure cookies. If accessing over plain HTTP:

# Verify N8N_SECURE_COOKIE is set to false
kubectl -n n8n-01 get deploy n8n-01 -o jsonpath='{.spec.template.spec.containers[0].env}' | python3 -m json.tool | grep -A1 SECURE_COOKIE

If missing, add N8N_SECURE_COOKIE: "false" to the deployment env vars. Remove it once TLS is configured.

PostgreSQL Connection Refused

# Check if PostgreSQL pod is running
kubectl -n n8n-01 get pods -l app.kubernetes.io/name=n8n-01-postgresql

# Check PostgreSQL logs for auth errors
kubectl -n n8n-01 logs -l app.kubernetes.io/name=n8n-01-postgresql --tail=20

Common cause: the existingSecret key names don’t match what Bitnami expects (postgres-password for admin, password for the app user).

Workflows Not Triggering on Schedule

Check that WEBHOOK_URL is set correctly in the deployment env. n8n uses this to construct callback URLs for webhooks and scheduled triggers. If it’s wrong or unreachable, scheduled workflows may silently fail.

kubectl -n n8n-01 get deploy n8n-01 -o jsonpath='{.spec.template.spec.containers[0].env}' | python3 -m json.tool | grep -A1 WEBHOOK
