Operating on GitOps

This post covers the day-to-day commands for working with ArgoCD on the frank cluster. If you want to understand how the App-of-Apps pattern was set up and why, see GitOps Everything with ArgoCD.

Overview

ArgoCD runs at 192.168.55.200 on a Cilium L2 LoadBalancer. It manages itself and every workload on the cluster through the App-of-Apps pattern. A single root Application in apps/root/ renders child Application CRs for each component — Cilium, Longhorn, the GPU Operator, LiteLLM, Sympozium, and everything else.

All ArgoCD CLI commands use port-forwarding since there is no public ingress:

argocd app list --port-forward --port-forward-namespace argocd

Every command in this post includes those flags. If you get tired of typing them, alias it:

alias argocd='argocd --port-forward --port-forward-namespace argocd'

Observing State

List All Applications

argocd app list --port-forward --port-forward-namespace argocd

This shows every application, its sync status (Synced, OutOfSync), health status (Healthy, Degraded, Progressing), and the target revision.

$ kubectl get application -n argocd -o wide 2>&1 | head -35
NAME                   SYNC STATUS   HEALTH STATUS   REVISION                                   PROJECT
argo-rollouts          Synced        Healthy                                                    infrastructure
argo-rollouts-extras   Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
argocd                 Synced        Healthy                                                    infrastructure
authentik              Synced        Healthy                                                    infrastructure
authentik-extras       Synced        Healthy         42c7a8b8349c99cb1c2b29a6547c860396a06af5   infrastructure
blackbox-exporter      Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
cert-manager           Synced        Healthy                                                    infrastructure
cilium                 Synced        Healthy                                                    infrastructure
cilium-config          Synced        Healthy         42c7a8b8349c99cb1c2b29a6547c860396a06af5   infrastructure
comfyui                Synced        Healthy         42c7a8b8349c99cb1c2b29a6547c860396a06af5   infrastructure
external-secrets       Synced        Healthy                                                    infrastructure
fluent-bit             Synced        Healthy                                                    infrastructure
gitea                  Synced        Progressing                                                infrastructure
gitea-extras           Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
gpu-operator           Synced        Healthy                                                    infrastructure
gpu-operator-extras    Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
gpu-switcher           Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
grafana-alerting       Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
health-bridge          Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
homepage               Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
infisical              Synced        Healthy                                                    infrastructure
infisical-extras       Synced        Healthy         42c7a8b8349c99cb1c2b29a6547c860396a06af5   infrastructure
infisical-postgresql   Synced        Healthy                                                    infrastructure
infisical-redis        Synced        Healthy                                                    infrastructure
intel-gpu-driver       Synced        Healthy                                                    infrastructure
litellm                Synced        Healthy                                                    infrastructure
litellm-extras         Synced        Progressing     42c7a8b8349c99cb1c2b29a6547c860396a06af5   infrastructure
longhorn               Synced        Healthy                                                    infrastructure
longhorn-extras        Synced        Healthy         42c7a8b8349c99cb1c2b29a6547c860396a06af5   infrastructure
n8n-01                 Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure
n8n-01-postgresql      Synced        Healthy                                                    infrastructure
ollama                 Synced        Healthy                                                    infrastructure
openrgb                Synced        Healthy         42c7a8b8349c99cb1c2b29a6547c860396a06af5   infrastructure
paperclip              Synced        Healthy         fe5f5900e397c6bda7158e9add7a7853007535d7   infrastructure

Inspect a Single Application

argocd app get cilium --port-forward --port-forward-namespace argocd

This returns the full resource tree: every Deployment, DaemonSet, Service, ConfigMap, and Secret that ArgoCD tracks for that application. Resources with sync issues are flagged individually, which tells you exactly which object is drifting.

Watch Sync Events

argocd app get cilium --port-forward --port-forward-namespace argocd --show-operation

The --show-operation flag shows the last sync operation result, including which resources were created, updated, or pruned and how long the operation took.

Routine Operations

Force Sync an Application

When you push a change and do not want to wait for the polling interval:

argocd app sync cilium --port-forward --port-forward-namespace argocd

For all applications at once, sync the root app:

argocd app sync root --port-forward --port-forward-namespace argocd

This re-renders the root Helm chart, which may discover new child Applications or updated chart versions. Each child then syncs on its own.

Hard Refresh

ArgoCD caches the Git repo and Helm chart index. If you need it to re-read everything immediately:

argocd app get cilium --port-forward --port-forward-namespace argocd --hard-refresh

Useful when you have pushed a commit but ArgoCD still shows the old state.

Check Diff Before Syncing

See what ArgoCD would change without applying anything:

argocd app diff cilium --port-forward --port-forward-namespace argocd

This is the GitOps equivalent of terraform plan. Review the diff, then sync if it looks right.

Add a New Application

Adding a new workload follows the App-of-Apps pattern:

Create apps/<app-name>/values.yaml with Helm values.
Create apps/root/templates/<app-name>.yaml with the Application CR.
Optionally add apps/<app-name>/manifests/ for raw Kubernetes manifests.
Commit, push, and sync the root app.

ArgoCD discovers the new Application CR from the root chart and begins syncing it automatically.

Manage ArgoCD Itself

ArgoCD manages its own Helm values through the same Git repo. After editing apps/argocd/values.yaml:

argocd app sync argocd --port-forward --port-forward-namespace argocd

Since ArgoCD is updating itself, watch for the server to restart. The CLI connection will drop momentarily and reconnect.

Debugging

Application Stuck in Degraded

An app showing Degraded usually means one or more of its resources failed to reach a healthy state. Start with the resource tree:

argocd app get <app> --port-forward --port-forward-namespace argocd

Look for resources marked Degraded or Missing. Then check the Kubernetes events:

kubectl describe deployment <name> -n <namespace>
kubectl get events -n <namespace> --sort-by=.lastTimestamp | tail -20

Common causes: image pull failures, resource limits too low, missing secrets, or nodes lacking the right taints/tolerations.

Sync Failed

When a sync operation fails, get the details:

argocd app get <app> --port-forward --port-forward-namespace argocd --show-operation

The operation result shows exactly which resource failed and why. Two frequent culprits:

Annotation size limit. Kubernetes has a 256KB limit on annotation values. Large CRDs (like Cilium’s) can exceed this with client-side apply. The fix is ServerSideApply=true in syncOptions, which the frank cluster uses on every application.
Finalizer deadlocks. A resource with a finalizer that references a deleted controller will hang forever. Check metadata.finalizers and remove the offending entry if the controller is genuinely gone.

OutOfSync but Correct

Some resources appear OutOfSync even though the live state is correct. This happens when a controller mutates the resource after ArgoCD applies it. Kubernetes Secrets are the classic example — controllers encode or rotate secret data, causing a permanent diff.

The fix is ignoreDifferences in the Application spec:

ignoreDifferences:
  - group: ""
    kind: Secret
    jsonPointers:
      - /data

The frank cluster already applies this to applications that manage auto-generated secrets (Cilium, cert-manager). If you see a new case, add the appropriate ignoreDifferences entry to the Application template in apps/root/templates/.

Orphaned Resources

With prune: false (the default on this cluster), ArgoCD never deletes resources that disappear from Git. This is intentional — accidental deletion of a CNI DaemonSet or a storage controller would be catastrophic.

To find resources ArgoCD no longer tracks:

argocd app resources <app> --port-forward --port-forward-namespace argocd --orphaned

Review the list and delete manually if you are sure:

kubectl delete <kind> <name> -n <namespace>

Quick Reference

Task	Command
List all apps	`argocd app list --port-forward --port-forward-namespace argocd`
Get app detail	`argocd app get <app> --port-forward --port-forward-namespace argocd`
Sync one app	`argocd app sync <app> --port-forward --port-forward-namespace argocd`
Sync everything	`argocd app sync root --port-forward --port-forward-namespace argocd`
Check diff	`argocd app diff <app> --port-forward --port-forward-namespace argocd`
Hard refresh	`argocd app get <app> --port-forward --port-forward-namespace argocd --hard-refresh`
Show last sync	`argocd app get <app> --port-forward --port-forward-namespace argocd --show-operation`
List orphans	`argocd app resources <app> --port-forward --port-forward-namespace argocd --orphaned`
App logs	`argocd app logs <app> --port-forward --port-forward-namespace argocd`
Delete an app	`argocd app delete <app> --port-forward --port-forward-namespace argocd`

References

ArgoCD Documentation — Official reference for all CLI commands and concepts
ArgoCD Sync Options — ServerSideApply, selfHeal, prune, and ignoreDifferences
GitOps Everything with ArgoCD — How the App-of-Apps was built on this cluster
