This is the operational runbook for Longhorn storage and Cloudflare R2 backups on Frank, the Talos Cluster. If you want the full story on how storage was set up, see Persistent Storage with Longhorn. For backup architecture and the Longhorn 1.11 gotchas that shaped the current design, see Backup — Longhorn to Cloudflare R2.

Overview

Frank runs Longhorn for distributed block storage. The default StorageClass replicates every volume three times across the control-plane nodes (mini-1, mini-2, mini-3). A second StorageClass, longhorn-gpu-local, provides single-replica strict-local storage pinned to gpu-1’s dedicated SSDs for AI workloads.

All volumes in the default group are backed up to a Cloudflare R2 bucket on two schedules:

  • Daily at 02:00 UTC — 7 recovery points retained
  • Weekly on Sunday at 03:00 UTC — 4 recovery points retained

Both RecurringJobs currently target R2 (NFS backup target is disabled pending a Longhorn bug fix in v1.13).

Observing State

Volume Health

List all Longhorn volumes and their current state:

kubectl get volumes.longhorn.io -n longhorn-system

A healthy volume shows State: attached (if in use) or State: detached (if idle), with Robustness: healthy. Anything showing degraded or faulted needs attention — jump to the Debugging section.

$ kubectl get volumes.longhorn.io -n longhorn-system
NAME                                       DATA ENGINE   STATE      ROBUSTNESS   SCHEDULED   SIZE           NODE      AGE
pvc-0ea5fae9-9f12-488e-83e8-a69e4b533b50   v1            attached   healthy                  32212254720    gpu-1     42d
pvc-1211b9cd-8062-43ca-8fa9-93ec43c36c35   v1            attached   healthy                  1073741824     mini-2    8d
pvc-184f9b50-5d7f-400d-865b-4bb587dcf859   v1            attached   healthy                  8589934592     mini-2    39d
pvc-1929c98e-6a59-4eec-8c41-353833f43dec   v1            attached   healthy                  5368709120     mini-2    37d
pvc-1b0925db-fc13-4a8f-99da-2a09265ada47   v1            detached   unknown                  10737418240              35d
pvc-1ded449d-e2bc-4e38-b7c9-c5d5ee264294   v1            attached   healthy                  2147483648     mini-3    37d
pvc-26d07ae3-35c9-406f-b963-01894b9db240   v1            attached   healthy                  21474836480    mini-3    43d
pvc-40c7a93f-5a74-49f0-8dc6-ff900348879a   v1            attached   healthy                  10737418240    gpu-1     21d
pvc-4b1121bb-2285-42ec-8a8d-49cc96978ae1   v1            attached   healthy                  5368709120     mini-1    42d
pvc-61ea0ef7-097a-4362-8727-19db3475a07c   v1            attached   healthy                  53687091200    gpu-1     20d
pvc-64409163-fd82-49d1-bdfd-6a2a97f339c6   v1            attached   healthy                  1073741824     mini-3    43d
pvc-6555d86e-52c3-4d36-9f3d-498053f0525c   v1            attached   healthy                  2147483648     mini-1    42d
pvc-6ff35220-82b3-478e-849d-f3dd9e0f29af   v1            attached   healthy                  1073741824     gpu-1     41d
pvc-82bfe595-d342-41c4-9f68-7346b2317a6d   v1            attached   healthy                  53687091200    pc-1      7d8h
pvc-9cfe443a-e7e9-4894-a169-943b361124a5   v1            attached   healthy                  21474836480    gpu-1     43d
pvc-b17ad456-1c3b-45dc-a6c9-18df39a4dab6   v1            attached   healthy                  134217728      raspi-1   12d
pvc-c1d1b3b5-4e57-4488-a921-40814dac625a   v1            attached   healthy                  10737418240    pc-1      22d
pvc-c700abbe-9114-47b8-ac5b-2f408f6055ec   v1            detached   unknown                  107374182400             36d
pvc-cd8722f8-2077-41d5-86eb-a62c6437dd3f   v1            attached   healthy                  5368709120     mini-3    21d
pvc-de4ab602-205f-41d5-8f13-1d2982109b92   v1            attached   healthy                  5368709120     mini-2    42d
pvc-f083c9f7-8cbe-4cb7-89d0-7455c59a6f50   v1            attached   healthy                  5368709120     mini-3    39d

For more detail on a specific volume:

kubectl get volume.longhorn.io <volume-name> -n longhorn-system -o yaml

Longhorn UI

The dashboard at http://192.168.55.201 gives you a visual overview of volume health, replica distribution, node capacity, and backup status. It is the fastest way to spot problems.

Backup Jobs

Check the RecurringJob schedule and retention:

kubectl get recurringjobs.longhorn.io -n longhorn-system

Check the backup target status (should show AVAILABLE: true):

kubectl get backuptargets.longhorn.io -n longhorn-system

List recent backups for a specific volume:

kubectl get backups.longhorn.io -n longhorn-system \
  -l longhornvolume=<volume-name> \
  --sort-by=.metadata.creationTimestamp

Node and Disk Status

See how much capacity each node has and whether disks are schedulable:

kubectl get nodes.longhorn.io -n longhorn-system -o wide

Routine Operations

Expand a Volume

Longhorn supports online volume expansion. Edit the PVC to request more storage:

kubectl patch pvc <pvc-name> -n <namespace> \
  -p '{"spec":{"resources":{"requests":{"storage":"20Gi"}}}}'

The underlying Longhorn volume and filesystem expand automatically. No pod restart needed for ext4; XFS may need a manual xfs_growfs inside the pod.

Trigger a Manual Backup

If you want an immediate backup outside the scheduled window (before maintenance, for example):

kubectl create -f - <<EOF
apiVersion: longhorn.io/v1beta2
kind: Backup
metadata:
  generateName: manual-backup-
  namespace: longhorn-system
  labels:
    longhornvolume: <volume-name>
spec:
  snapshotName: ""
EOF

Leaving snapshotName empty tells Longhorn to take a fresh snapshot and back it up. You can track progress in the Longhorn UI under Backup.

Restore a Volume from Backup

To restore a volume from an R2 backup:

  1. Open the Longhorn UI at http://192.168.55.201
  2. Navigate to Backup and find the volume
  3. Select the recovery point (daily or weekly) and click Restore
  4. Choose the number of replicas and target StorageClass
  5. Longhorn creates a new volume — create a PVC to bind it

Alternatively, via CLI, create a new volume referencing the backup URL:

kubectl create -f - <<EOF
apiVersion: longhorn.io/v1beta2
kind: Volume
metadata:
  name: restored-<volume-name>
  namespace: longhorn-system
spec:
  fromBackup: "s3://frank-longhorn-backups@auto/?backup=<backup-name>&volume=<volume-name>"
  numberOfReplicas: 3
  dataLocality: best-effort
EOF

Then create a PV and PVC pointing to the restored volume, or use the Longhorn UI to create the PVC automatically.

Manage Snapshots

List snapshots for a volume:

kubectl get snapshots.longhorn.io -n longhorn-system \
  -l longhornvolume=<volume-name>

Delete old snapshots manually (Longhorn retains per the RecurringJob retain count, but you can clean up extras):

kubectl delete snapshot.longhorn.io <snapshot-name> -n longhorn-system

Verify R2 Backup Credentials

If backups start failing, check the secret is present and the backup target reports available:

kubectl get secret longhorn-r2-secret -n longhorn-system
kubectl get backuptargets.longhorn.io -n longhorn-system

If the secret was lost (node rebuild, namespace wipe), re-apply it from the encrypted source:

sops --decrypt secrets/longhorn/r2-secret.yaml | kubectl apply -f -

Debugging

Volume Degraded

A degraded volume has fewer healthy replicas than requested. Common causes:

# Check which replicas are unhealthy
kubectl get replicas.longhorn.io -n longhorn-system \
  -l longhornvolume=<volume-name>

# Check node status — is a node offline?
kubectl get nodes
kubectl get nodes.longhorn.io -n longhorn-system

If a node is down temporarily (reboot, maintenance), Longhorn will rebuild the replica when the node returns. If a node is permanently gone, Longhorn auto-rebuilds on remaining nodes once nodeDownPodDeletionPolicy kicks in.

Force-rebuild a replica on a different node by deleting the failed replica:

kubectl delete replica.longhorn.io <replica-name> -n longhorn-system

Longhorn schedules a new replica on a healthy node automatically.

Backup Failed

Check the backup target availability first:

kubectl get backuptargets.longhorn.io -n longhorn-system -o yaml

Look at the status.conditions — common failures:

  • Credential error: R2 secret missing or wrong. Verify with kubectl get secret longhorn-r2-secret -n longhorn-system -o yaml and check that AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY, and AWS_ENDPOINTS are all present.
  • Network error: Check DNS resolution and outbound HTTPS connectivity from a Longhorn pod.
  • Bucket not found: Verify the bucket name matches what is in the backupTargetURL.

Check the Longhorn manager logs for detailed error messages:

kubectl logs -n longhorn-system -l app=longhorn-manager --tail=50 | grep -i backup

Volume Stuck Attaching

A volume stuck in attaching state usually means iSCSI issues:

# Check the volume attachment status
kubectl describe volume.longhorn.io <volume-name> -n longhorn-system

# Check the engine status
kubectl get engines.longhorn.io -n longhorn-system \
  -l longhornvolume=<volume-name> -o yaml

# Verify iSCSI is running on the target node
talosctl -n <node-ip> services | grep iscsid

If iSCSI is not running, the iscsi-tools extension may have been lost during an upgrade. Verify extensions on the node:

talosctl -n <node-ip> get extensions

As a last resort, force-detach and re-attach:

kubectl patch volume.longhorn.io <volume-name> -n longhorn-system \
  --type merge -p '{"spec":{"nodeID":""}}'

This clears the node assignment and lets Longhorn re-attach the volume when the consuming pod is rescheduled.

Quick Reference

TaskCommand
List volumeskubectl get volumes.longhorn.io -n longhorn-system
Volume detailkubectl get volume.longhorn.io <name> -n longhorn-system -o yaml
List replicaskubectl get replicas.longhorn.io -n longhorn-system
List backupskubectl get backups.longhorn.io -n longhorn-system
Backup target statuskubectl get backuptargets.longhorn.io -n longhorn-system
Recurring jobskubectl get recurringjobs.longhorn.io -n longhorn-system
Expand PVCkubectl patch pvc <name> -n <ns> -p '{"spec":{"resources":{"requests":{"storage":"<size>"}}}}'
Re-apply R2 secretsops --decrypt secrets/longhorn/r2-secret.yaml | kubectl apply -f -
Longhorn manager logskubectl logs -n longhorn-system -l app=longhorn-manager --tail=50
Node disk capacitykubectl get nodes.longhorn.io -n longhorn-system -o wide
Longhorn UIhttp://192.168.55.201
