In-Cluster Ingress — Traefik, Wildcard TLS, and a Homepage Dashboard

In-Cluster Ingress — Traefik, Wildcard TLS, and a Homepage Dashboard

Up until now, all of Frank’s services were reachable via direct Cilium L2 LoadBalancer IPs — type an IP and port into your browser, and you’re in. That works fine on a local network, but it means no TLS, no unified authentication, no human-readable URLs, and no single place to see what’s running. The external Traefik on raspi-omni handled *.frank.derio.net routing, but it sat outside the cluster — a separate Ansible-managed box with its own failure modes.

This post moves the ingress controller inside the cluster: Traefik v3 running on the raspi edge nodes, serving all services under *.cluster.derio.net with wildcard TLS from Let’s Encrypt, Authentik forward-auth for services without native SSO, and a gethomepage.dev dashboard at master.cluster.derio.net.

Architecture

Pi-hole (HA pair)
  *.cluster.derio.net → 192.168.55.220
                              │
                    Traefik (in-cluster)
                    ├─ Cilium L2 LoadBalancer (192.168.55.220)
                    ├─ TLS via built-in ACME (Let's Encrypt + Cloudflare DNS-01)
                    ├─ Wildcard cert: *.cluster.derio.net
                    ├─ Middleware chain: IP allowlist + security headers
                    └─ Node placement: raspi-1/raspi-2 (zone: edge)
                              │
              ┌───────────────┴───────────────┐
        Forward-auth services           Direct proxy services
        (via Authentik outpost)         (native auth or public)
              │                               │
  Longhorn, Hubble, ComfyUI,       ArgoCD, Sympozium, Authentik,
  Infisical, LiteLLM, Grafana,     Homepage
  GPU Switcher, Paperclip,
  n8n, Gitea, Zot, Tekton

Traefik runs as a single-replica Deployment on the raspi edge nodes. A Cilium L2 announcement puts it at 192.168.55.220. Pi-hole resolves *.cluster.derio.net to that IP. Traefik terminates TLS with a wildcard cert, applies middleware, and routes to backend services via Kubernetes DNS — traffic stays cluster-internal, no hairpin through L2.

Why Traefik

I evaluated Traefik, Envoy Gateway, and Contour. Traefik won on:

  • Authentik integration — official docs, battle-tested forward-auth middleware
  • Resource footprint — single pod, ~50MB idle, proven on RPi 4 ARM64
  • Familiarity — same middleware model as the existing Ansible-managed Traefik, near 1:1 translation
  • Gateway API — supports v1.4 for future migration without changing controllers

TLS: Built-in ACME, Not cert-manager

cert-manager is already deployed for internal webhook TLS, but for this use case Traefik’s built-in ACME resolver is simpler — no extra CRDs, no Issuer/Certificate objects. One wildcard cert for *.cluster.derio.net via Cloudflare DNS-01:

# apps/traefik/values.yaml (excerpt)
certificatesResolvers:
  cloudflare:
    acme:
      email: "admin@derio.net"
      storage: /data/acme.json
      dnsChallenge:
        provider: cloudflare
        propagation:
          disableChecks: true
          delayBeforeChecks: 60

The disableChecks: true skips local DNS propagation verification (blocked by router ACLs), and delayBeforeChecks: 60 gives Cloudflare 60 seconds to propagate the TXT record globally before Let’s Encrypt verifies it.

The cert is stored in acme.json on a small 128Mi Longhorn PV. Since the PV is RWO, Traefik runs with strategy: Recreate — no rolling updates, but that’s fine for a single-replica edge proxy.

$ kubectl -n traefik-system exec deploy/traefik -- cat /data/acme.json 2>/dev/null | jq -r ".cloudflare.Certificates[].domain.main"
*.cluster.derio.net

$ kubectl -n traefik-system exec deploy/traefik -- cat /data/acme.json 2>/dev/null | jq -r ".cloudflare.Certificates[0].certificate" | base64 -d | openssl x509 -noout -dates
notBefore=Apr  8 05:28:35 2026 GMT
notAfter=Jul  7 05:28:34 2026 GMT

PVC Permissions Gotcha

Longhorn creates root-owned volumes, but Traefik runs as uid 65532 (nonroot). Without fsGroup, the ACME resolver fails silently with permission denied on /data/acme.json — Traefik logs it as “ACME resolve is skipped from the resolvers list” and every IngressRoute complains about a “nonexistent certificate resolver”:

podSecurityContext:
  fsGroup: 65532
  fsGroupChangePolicy: "OnRootMismatch"

The Traefik Helm chart uses top-level podSecurityContext, not deployment.podSecurityContext — the nested path is silently ignored.

Middlewares

Three Middleware CRDs in traefik-system:

security-headers — HSTS, X-Frame-Options, Content-Type sniffing protection, referrer policy. Mirrors the existing raspi-omni config.

ip-allowlist — restricts to RFC 1918 ranges (10.0.0.0/8, 192.168.0.0/16, 172.16.0.0/12). This is a homelab, not a public-facing cluster.

authentik-forwardauth — sends every request to the Authentik embedded outpost for authentication. The outpost checks the user’s session cookie; if missing or expired, it redirects to the Authentik login page:

spec:
  forwardAuth:
    address: "http://authentik-server.authentik.svc.cluster.local:80/outpost.goauthentik.io/auth/traefik"
    trustForwardHeader: true
    authResponseHeaders:
      - X-authentik-username
      - X-authentik-groups
      - X-authentik-email
      # ... plus uid, jwt, meta headers

The Authentik ClusterIP service exposes port 80 (mapped to pod port 9000). Using in-cluster DNS means forward-auth stays entirely within the cluster network.

IngressRoutes

All 16 IngressRoutes live in a single ingressroutes.yaml. Each route targets the websecure entrypoint with the wildcard cert resolver and at least ip-allowlist + security-headers middlewares.

Services split into two tiers:

Direct proxy (no forward-auth): ArgoCD, Sympozium, Authentik, Homepage — these either have their own login page or are the IdP itself.

Forward-auth via Authentik: Grafana, Longhorn, Hubble, Infisical, LiteLLM, Paperclip, ComfyUI, GPU Switcher, n8n, Gitea, Zot, Tekton — services without native OIDC (or with OIDC configured for frank.derio.net, not yet migrated).

Backend services are referenced via Kubernetes DNS (service.namespace:port), not Cilium L2 IPs. Traffic stays cluster-internal via Cilium eBPF routing.

$ kubectl get ingressroutes -n traefik-system -o wide
NAME           AGE
argocd         12d
authentik      12d
comfyui        12d
gitea          12d
gpu-switcher   12d
grafana        12d
homepage       12d
hubble         12d
infisical      12d
litellm        12d
longhorn       12d
n8n            12d
paperclip      12d
sympozium      12d
tekton         12d
vk-remote      8d
zot            12d

Authentik Blueprints

The proxy providers for *.cluster.derio.net are managed declaratively via an Authentik blueprint ConfigMap (blueprints-cluster-proxy-providers.yaml). Each service gets a forward_single proxy provider entry:

- model: authentik_providers_proxy.proxyprovider
  state: present
  identifiers:
    name: Grafana (cluster)
  attrs:
    authorization_flow: !Find [authentik_flows.flow, [slug, default-provider-authorization-implicit-consent]]
    authentication_flow: !Find [authentik_flows.flow, [slug, default-authentication-flow]]
    invalidation_flow: !Find [authentik_flows.flow, [slug, default-provider-invalidation-flow]]
    mode: forward_single
    external_host: https://grafana.cluster.derio.net

The invalidation_flow field is required in Authentik 2026.x — without it, the blueprint fails silently with a serializer error and no providers are created.

The blueprint creates providers and applications, but does not assign them to the embedded outpost. Outpost assignment must be done via Django ORM after the blueprint applies — Authentik blueprints can’t append to an outpost’s provider list without replacing existing assignments.

Homepage Dashboard

A gethomepage.dev instance at master.cluster.derio.net provides the cluster landing page — all services organized by category with HTTP health indicators:

  • Infrastructure: ArgoCD, Longhorn, Hubble, Grafana, Infisical, Authentik
  • CI/CD: Gitea, Zot, Tekton
  • Development: LiteLLM, Sympozium, n8n, Paperclip, ComfyUI, GPU Switcher

Health checks use siteMonitor (HTTP HEAD/GET to internal ClusterIP URLs), not ping (ICMP) — Kubernetes ClusterIP addresses don’t respond to ICMP from inside the cluster.

Custom bookmarks link to the Lab landing page, Omni, and Renovate.

Gotchas

IssueFix
acme.json: permission deniedpodSecurityContext.fsGroup: 65532 (top-level, not nested under deployment)
ACME DNS-01 NXDOMAINpropagation.delayBeforeChecks: 60 — give Cloudflare time to propagate TXT records
disablePropagationCheck deprecatedUse propagation.disableChecks: true in Traefik v3.6+
Authentik blueprint invalidation_flow requiredAuthentik 2026.x serializer rejects providers without it
Blueprint doesn’t assign outpostManual Django ORM: outpost.providers.add(provider) after blueprint applies
Homepage ping: shows DOWNUse siteMonitor: (HTTP) instead — ICMP doesn’t work for ClusterIP
Homepage Host validation failedSet HOMEPAGE_ALLOWED_HOSTS=master.cluster.derio.net env var
