Media Generation — ComfyUI and GPU Time-Sharing

The cluster has one GPU. Layer 10 gave it to Ollama for LLM inference. This layer adds a second GPU consumer — ComfyUI for diffusion-based media generation — and a mechanism to share the hardware between them.

The Constraint: One GPU, Two Workloads

The RTX 5070 Ti on gpu-1 has 16GB of GDDR7 VRAM. That’s enough for one heavy workload at a time, but not two simultaneously. LTX-2.3 (the video diffusion model) needs 8-12GB of VRAM for inference. Ollama with a 9B parameter model uses 6-7GB. Running both means neither has enough memory for useful context or batch sizes.

Time-sharing is the answer: scale one workload to zero replicas, let the other use the full GPU, then swap when needed. Both Deployments request nvidia.com/gpu: 1, so Kubernetes won’t schedule them concurrently — the GPU is a discrete resource. Only the workload with replicas: 1 actually runs.

Architecture

gpu-1 (RTX 5070 Ti, 16GB VRAM)
├── ollama (replicas: 1, default active)
│   └── LLM inference — qwen3.5:9b, deepseek-coder:6.7b
└── comfyui (replicas: 0, scaled up on demand)
    └── Diffusion models — LTX-2.3 (video), SDXL (image), Stable Audio

gpu-switcher (any amd64 node)
└── Web dashboard at 192.168.55.214:8080
    ├── Shows which workload owns the GPU
    ├── One-click activate/deactivate
    └── Patches Deployment replicas via K8s API

Three ArgoCD apps, all using raw manifests (no upstream Helm chart):

ComfyUI

ComfyUI is a node-based visual editor for diffusion model pipelines. It supports text-to-video (LTX-2.3), text-to-image (SDXL, Flux), and text-to-audio (Stable Audio). The web UI runs a graph editor where you wire model nodes, samplers, and output nodes together. It also exposes a REST API for programmatic use.

The Deployment:

containers:
  - name: comfyui
    image: ghcr.io/ai-dock/comfyui:latest
    resources:
      requests:
        nvidia.com/gpu: 1
      limits:
        nvidia.com/gpu: 1

Key decisions:

• 100Gi PVC on Longhorn gpu-local StorageClass — models are large (LTX-2.3 alone is ~4GB, SDXL is ~7GB). This volume mounts at /workspace and persists across pod restarts.
• Starts at 0 replicas — Ollama is the default active workload. ComfyUI only starts when explicitly switched via the GPU Switcher.
• Node affinity to gpu-1 — the only node with a discrete GPU.

GPU Switcher

The GPU Switcher is a custom Go web application that provides a dashboard for managing GPU time-sharing. It runs as a lightweight pod (50m CPU, 32Mi memory) on any amd64 node — it doesn’t need a GPU itself.

How It Works

The application reads a WORKLOADS environment variable that defines the managed workloads:

WORKLOADS=ollama:ollama:ollama,comfyui:comfyui:comfyui

Format: name:namespace:deployment — so ollama:ollama:ollama means “the workload called ollama is the Deployment named ollama in the ollama namespace”.

On each status check, it queries the Kubernetes API for each Deployment’s replica count and pod status. The dashboard shows which workload currently owns the GPU. Activating a workload scales it to 1 replica and scales all others to 0.

The ArgoCD Problem

ArgoCD’s self-heal feature normally detects drift between the Git state and the live cluster, then corrects it. If Git says replicas: 0 for ComfyUI but the GPU Switcher just scaled it to 1, ArgoCD would scale it back to 0 within minutes.

The fix: ignoreDifferences on spec.replicas in both the ComfyUI and Ollama Application CRs:

spec:
  ignoreDifferences:
    - group: apps
      kind: Deployment
      jsonPointers:
        - /spec/replicas

This tells ArgoCD to ignore replica count differences — the GPU Switcher is the authority for that field, not Git.

RBAC

The GPU Switcher’s ServiceAccount needs cross-namespace access:

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: gpu-switcher
rules:
  - apiGroups: ["apps"]
    resources: ["deployments"]
    verbs: ["get", "list", "patch"]
  - apiGroups: ["apps"]
    resources: ["deployments/scale"]
    verbs: ["get", "patch"]
  - apiGroups: [""]
    resources: ["pods"]
    verbs: ["get", "list"]

A ClusterRole (not a namespaced Role) because it patches Deployments in both the ollama and comfyui namespaces.

$ curl -s http://192.168.55.214:8080/api/status | jq
[
  {
    "name": "ollama",
    "namespace": "ollama",
    "replicas": 1,
    "readyReplicas": 1,
    "podPhase": "Running"
  },
  {
    "name": "comfyui",
    "namespace": "comfyui",
    "replicas": 0,
    "readyReplicas": 0,
    "podPhase": "None"
  }
]

Building the Image

The GPU Switcher is a static Go binary in a distroless container. Building on an arm64 Mac for amd64 cluster nodes required some care:

# Cross-compile natively (no QEMU)
CGO_ENABLED=0 GOOS=linux GOARCH=amd64 go build -ldflags="-s -w" -o gpu-switcher-linux-amd64 .

# Package into amd64 distroless runtime
docker buildx build --platform linux/amd64 \
  -t ghcr.io/derio-net/gpu-switcher:v0.1.1 \
  --push .

The first build attempt used Docker’s --platform flag on the full multi-stage build, which tried to run the Go compiler under QEMU emulation — and crashed with a SIGSEGV in the Go runtime’s garbage collector. The working approach: compile the Go binary natively on the host (arm64) with GOARCH=amd64, then use a single-stage Dockerfile that just copies the pre-built binary into a --platform linux/amd64 distroless image.

The second attempt pushed an image with arm64 in its OCI manifest despite containing an amd64 binary — Docker inherits the manifest platform from the build host, not from FROM --platform. Using docker buildx build --push with explicit --platform linux/amd64 on a single-stage Dockerfile (no emulated build steps) fixed the manifest.

Model Downloads

ComfyUI models must be downloaded into the PVC after first deployment. This is a manual operation — the models are large and require specific placement:

# After switching GPU to ComfyUI via the Switcher
kubectl exec -it -n comfyui deploy/comfyui -- bash

# Inside the pod — download models to the persistent volume
cd /workspace/ComfyUI/models
# LTX-2.3 video model
wget -P video_models/ https://huggingface.co/Lightricks/LTX-Video/resolve/main/ltx-video-2b-v0.9.5.safetensors
# SDXL base
wget -P checkpoints/ https://huggingface.co/stabilityai/stable-diffusion-xl-base-1.0/resolve/main/sd_xl_base_1.0.safetensors

This step is documented in the manual operations runbook.

What’s Running

After deployment:

• Ollama holds the GPU (replicas: 1) — the default state
• ComfyUI is idle (replicas: 0) — waiting to be activated
• GPU Switcher shows the dashboard at 192.168.55.214:8080

To generate a video: open the GPU Switcher, click “Activate” on ComfyUI (which deactivates Ollama), wait for the pod to start (~30s), then open ComfyUI at 192.168.55.213:8188. When done, switch back to Ollama.

The cluster now has both LLM inference and media generation on a single GPU, with clean time-sharing managed through a web dashboard.
