GPU Compute — NVIDIA and Intel

GPU Compute — NVIDIA and Intel

This post covers two GPU paths that converged on the same cluster. The NVIDIA RTX 5070 in gpu-1 started as a cautionary tale — a card that booted fans and RGB but refused to appear on the PCIe bus — and ended with a successful reseat and a fully deployed GPU Operator. Meanwhile, the Intel Arc iGPUs hiding inside the three mini nodes became fully operational through Kubernetes 1.35’s Dynamic Resource Allocation — the new standard for GPU scheduling that replaces device plugins.

Both paths required Talos extensions, kernel-level config, and some chart surgery. Let’s walk through them.

Part 1: NVIDIA GPU Operator (Layer 4)

The plan for gpu-1 was straightforward: install NVIDIA’s Talos extensions, load the kernel modules, deploy the GPU Operator via Helm, and start scheduling CUDA workloads. The infrastructure side worked. The hardware had other ideas.

Talos Extensions for NVIDIA

Talos Linux uses a read-only, immutable root filesystem. You cannot apt install or modprobe anything at runtime. Instead, you bake system extensions into the node’s image schematic. For NVIDIA, two extensions are required:

  • nvidia-container-toolkit-production — the container runtime hooks that let containers access the GPU
  • nvidia-open-gpu-kernel-modules-production — the open-source NVIDIA kernel driver

On Sidero Omni, you declare extensions per machine using ExtensionsConfigurations:

# patches/phase04-gpu/402-gpu1-nvidia-extensions.yaml
metadata:
    type: ExtensionsConfigurations.omni.sidero.dev
    id: 402-gpu1-nvidia-extensions
    labels:
        omni.sidero.dev/cluster: frank
        omni.sidero.dev/cluster-machine: 03ff0210-...
spec:
    extensions:
        - siderolabs/iscsi-tools
        - siderolabs/nvidia-container-toolkit-production
        - siderolabs/nvidia-open-gpu-kernel-modules-production

A critical gotcha here: per-machine ExtensionsConfiguration resources in Omni override the cluster-wide config entirely — they do not merge. If the cluster already has iscsi-tools (needed for Longhorn), you must re-include it in the per-machine config or gpu-1 will lose iSCSI support and Longhorn will break on that node.

Applying the extension triggers an image rebuild and a reboot. Once the node comes back, the second patch loads the kernel modules:

# patches/phase04-gpu/04-gpu-nvidia-modules.yaml (abbreviated)
spec:
    data: |
        machine:
            kernel:
                modules:
                    - name: nvidia
                    - name: nvidia_uvm
                    - name: nvidia_modeset
                    - name: nvidia_drm

The ordering matters: extensions must be in the image schematic before you try to load the modules. Apply the extension config first, wait for the node to come back Ready, then apply the module patch.

GPU Operator Helm Values

With the driver and toolkit baked into Talos itself, the NVIDIA GPU Operator’s job shrinks considerably. Most of its default components would try to install things that Talos already provides (and cannot modify anyway). The values file is deliberately minimal:

# apps/gpu-operator/values.yaml
driver:
  enabled: false

toolkit:
  enabled: false

operator:
  defaultRuntime: containerd

driver.enabled: false because Talos provides the kernel modules. toolkit.enabled: false because Talos provides the container toolkit. The operator still handles device discovery, the device plugin, GPU feature discovery, and the DCGM exporter — all the Kubernetes-level plumbing.

The ArgoCD Application for the GPU Operator uses NVIDIA’s official Helm chart at v25.10.1:

# apps/root/templates/gpu-operator.yaml (abbreviated)
spec:
  sources:
    - repoURL: https://helm.ngc.nvidia.com/nvidia
      chart: gpu-operator
      targetRevision: "v25.10.1"
      helm:
        valueFiles:
          - $values/apps/gpu-operator/values.yaml
  syncPolicy:
    # Manual sync — GPU hardware not yet detected

Notice the sync policy: no automated block. This is intentional, and brings us to the hardware saga.

The Hardware Saga

The RTX 5070 is physically installed in gpu-1. The Gigabyte Z790 Eagle AX motherboard has a PCIe 5.0 x16 slot. The card is seated, powered (dual 8-pin), and the fans spin on boot. The RGB on the case fans (controlled via a separate USB HID controller) works fine.

Initially, the card was completely invisible to the PCIe bus — lspci showed nothing, no NVIDIA vendor ID 10de, silence. The NVIDIA kernel modules would load without error and simply find no hardware to bind to. The GPU Operator deployed fine from a software perspective, but there was no GPU to operate on.

What was tried before the fix:

  • BIOS settings — confirmed PCIe set to Auto/Gen5, CSM disabled, Above 4G Decoding enabled, Resizable BAR enabled.
  • Different BIOS versions — updated from the factory BIOS (predating the RTX 50-series) to the latest available. No change.
  • Power supply — verified PSU rail stability with a multimeter on the PCIe power connectors.

The fix: reseating the card. Removing and firmly reinstalling the RTX 5070 in the x16 slot resolved the detection issue. The kernel boot log now shows the card enumerating on the PCIe bus:

$ talosctl -n 192.168.55.31 dmesg | grep "0000:01:00.0"
pci 0000:01:00.0: [10de:2c05] type 00 class 0x030000 PCIe Legacy Endpoint
pci 0000:01:00.0: BAR 1 [mem 0x4800000000-0x4bffffffff 64bit pref]
pci 0000:01:00.0: 32.000 Gb/s available PCIe bandwidth, limited by 2.5 GT/s PCIe x16 link
pci 0000:01:00.0: vgaarb: setting as boot VGA device

Vendor ID 10de is NVIDIA, confirming the RTX 5070 is now visible to the PCIe bus. There is one quirk in the output: the link is negotiating at 2.5 GT/s (PCIe Gen 1) rather than the expected 32 GT/s (Gen 5). The card is capable of 504 Gb/s at full Gen 5 x16 width — but the BIOS is training the link at Gen 1. This is a known issue with some Z790 boards and the RTX 50-series requiring a BIOS update to negotiate Gen 5 properly. The reduced bandwidth affects workloads that are PCIe-transfer-bound (like streaming large tensors from host to GPU), but compute-bound workloads run at full GPU speed regardless.

With the card detected, the NVIDIA kernel module loads and binds:

$ talosctl -n 192.168.55.31 dmesg | grep NVRM
NVRM: loading NVIDIA UNIX Open Kernel Module for x86_64  570.211.01

And DRI devices appear on the node:

$ talosctl -n 192.168.55.31 ls /dev/dri
card0
renderD128

The Talos NVIDIA extensions are also confirmed active via the node labels that the extension system writes during boot:

$ kubectl get node gpu-1 --show-labels | tr ',' '\n' | grep nvidia
extensions.talos.dev/nvidia-container-toolkit-production=570.211.01-v1.18.2
extensions.talos.dev/nvidia-open-gpu-kernel-modules-production=570.211.01-v1.12.4
nvidia.com/gpu.present=true
nvidia.com/gpu.deploy.device-plugin=true
nvidia.com/gpu.deploy.dcgm=true
nvidia.com/gpu.deploy.dcgm-exporter=true
nvidia.com/gpu.deploy.gpu-feature-discovery=true
nvidia.com/gpu.deploy.operator-validator=true

nvidia.com/gpu.present=true is the GPU Operator’s node feature discovery confirming a physical NVIDIA GPU is detected. The nvidia.com/gpu.deploy.* labels tell the operator which components to instantiate on this node.

The ArgoCD Application was updated from manual sync to automated:

syncPolicy:
  automated:
    prune: false
    selfHeal: true
$ argocd app get gpu-operator
Health Status:  Healthy
Sync Policy:    Automated

This is the kind of thing that does not show up in architecture diagrams. A connection that was making just enough contact to power the fans but not enough to establish PCIe signaling — fixed by a firm reseat. The software stack was ready and waiting; the hardware just needed to catch up.

$ POD=$(kubectl get pod -n gpu-operator -l app=nvidia-dcgm-exporter -o jsonpath="{.items[0].metadata.name}"); kubectl exec -n gpu-operator "$POD" -c nvidia-dcgm-exporter -- nvidia-smi
Mon Apr 20 17:23:30 2026
+-----------------------------------------------------------------------------------------+
| NVIDIA-SMI 570.211.01             Driver Version: 570.211.01     CUDA Version: 12.8     |
|-----------------------------------------+------------------------+----------------------+
| GPU  Name                 Persistence-M | Bus-Id          Disp.A | Volatile Uncorr. ECC |
| Fan  Temp   Perf          Pwr:Usage/Cap |           Memory-Usage | GPU-Util  Compute M. |
|                                         |                        |               MIG M. |
|=========================================+========================+======================|
|   0  NVIDIA GeForce RTX 5070 Ti     Off |   00000000:01:00.0 Off |                  N/A |
|  0%   33C    P8             19W /  300W |    7956MiB /  16303MiB |      0%      Default |
|                                         |                        |                  N/A |
+-----------------------------------------+------------------------+----------------------+

Part 2: Intel Arc iGPU via DRA (Layer 5)

The three mini nodes (mini-1, mini-2, mini-3) each have an Intel Core Ultra with an integrated Intel Arc GPU. These are not powerhouse GPUs — they share system RAM instead of having dedicated VRAM, which makes them unsuitable for LLM inference (where memory bandwidth is the bottleneck). Where they shine is media and vision workloads: hardware video transcode via Quick Sync, object detection and computer vision via OpenVINO, and OpenCL compute. More importantly, they gave us a reason to implement DRA — the replacement for the Kubernetes device plugin model.

Why DRA Over Device Plugins?

Kubernetes has used device plugins since v1.10 to expose hardware like GPUs. A device plugin runs on each node, advertises a resource (like nvidia.com/gpu: 1), and pods request it through resources.limits. It works, but it has real limitations:

  • Devices are opaque integers in resources.limits — you cannot express “I want a GPU with at least 4GB VRAM” or “give me a GPU from the same NUMA node as my CPU allocation.”
  • Allocation is first-come-first-served with no structured claim semantics.
  • There is no standard way for a device to be shared between containers in a pod, or between pods with different permission levels.

Dynamic Resource Allocation (DRA), which graduated to GA in Kubernetes 1.32 and uses resource.k8s.io/v1, introduces three new concepts:

ResourceSlice — Published by the driver on each node, a ResourceSlice advertises what devices are available. Think of it as the driver saying “this node has an Intel Arc GPU with these capabilities.” Unlike device plugins, the slice can carry structured attributes (device model, memory, features) that schedulers can match against.

DeviceClass — A cluster-wide object that defines a class of devices. It uses CEL expressions to select which devices match. For Intel GPUs:

apiVersion: resource.k8s.io/v1
kind: DeviceClass
metadata:
  name: gpu.intel.com
spec:
  selectors:
  - cel:
      expression: device.driver == "gpu.intel.com"

ResourceClaim — The pod-side object that requests a device. Instead of resources.limits: gpu.intel.com/i915: 1, a pod creates a ResourceClaim that references the DeviceClass. The scheduler finds a node whose ResourceSlice has a matching device, binds the claim, and the kubelet plugin injects the device into the container via CDI (Container Device Interface).

A smoke-test pod using DRA looks like this:

apiVersion: v1
kind: Pod
metadata:
  name: gpu-test
spec:
  containers:
  - name: test
    image: ubuntu
    command: ["ls", "-la", "/dev/dri/"]
    resources:
      claims:
      - name: gpu
  resourceClaims:
  - name: gpu
    deviceClassName: gpu.intel.com

No magic resource strings in limits. The claim is a first-class Kubernetes object with its own lifecycle, and the DeviceClass provides a layer of abstraction between “what the pod wants” and “what the node has.”

i915 Extensions on Talos

The Intel Arc iGPU needs the i915 kernel driver and updated microcode. On Talos, these come as system extensions:

# patches/phase05-mini-config/500-mini1-i915-extensions.yaml
metadata:
    type: ExtensionsConfigurations.omni.sidero.dev
    id: 500-mini1-i915-extensions
spec:
    extensions:
        - siderolabs/iscsi-tools
        - siderolabs/i915
        - siderolabs/intel-ucode

The same iscsi-tools gotcha from Layer 4 applies: per-machine extension configs override the cluster-wide list, so iscsi-tools must be re-included.

There are three separate files — one per mini node (500-mini1, 501-mini2, 502-mini3) — because all three mini nodes are control-plane members. Applying an extension triggers an image rebuild and reboot. If you apply all three simultaneously, you lose quorum and the cluster goes down.

The safe procedure is serial: apply to mini-1, watch it reboot and return to Ready, then apply to mini-2, wait again, then mini-3. With Talos reboots taking roughly 60-90 seconds each, the whole process takes about five minutes but the cluster never loses availability.

# One node at a time — never lose quorum
omnictl apply -f patches/phase05-mini-config/500-mini1-i915-extensions.yaml
kubectl get node mini-1 -w   # wait for Ready

omnictl apply -f patches/phase05-mini-config/501-mini2-i915-extensions.yaml
kubectl get node mini-2 -w   # wait for Ready

omnictl apply -f patches/phase05-mini-config/502-mini3-i915-extensions.yaml
kubectl get node mini-3 -w   # wait for Ready

After the extensions are loaded, each node exposes the GPU devices:

$ talosctl -n 192.168.55.21 ls /dev/dri
card0
renderD128

CDI Containerd Configuration

DRA drivers inject devices into containers using the Container Device Interface (CDI). The driver writes a CDI spec file to a directory on the host, and containerd reads it when starting a container. By default, the Intel driver writes to /etc/cdi/.

On Talos, /etc is part of the read-only root filesystem. Writes to /etc/cdi/ silently fail or error out. The fix: tell both containerd and the driver to use /var/cdi/ instead, since /var is writable on Talos.

This is a cluster-wide Omni config patch (harmless on nodes without Intel GPUs):

# patches/phase05-mini-config/05-mini-cdi-containerd.yaml
spec:
    data: |
        machine:
            files:
                - path: /etc/cri/conf.d/20-customization.part
                  op: create
                  content: |
                      [plugins."io.containerd.cri.v1.runtime"]
                        cdi_spec_dirs = ["/var/cdi/static", "/var/cdi/dynamic"]

Talos supports containerd config drop-ins at /etc/cri/conf.d/. By writing a customization part file, we override the CDI spec directories without modifying the main containerd config. Containerd restarts automatically when this file appears — no node reboot required.

Chart Vendoring for K8s 1.35

The Intel GPU resource driver has an official Helm chart, but it was built for Kubernetes 1.32-1.34. Our cluster runs Kubernetes 1.35, which introduced a breaking change: the resource.k8s.io/v1beta1 API was removed. The upstream chart uses v1beta1 for its DeviceClass and references it in the ValidatingAdmissionPolicy.

Rather than maintaining a fragile set of Kustomize overlays or post-render hooks, I vendored the chart into the repo and patched it directly. The vendored chart lives at apps/intel-gpu-driver/chart/ with version 0.7.0-k8s135 to distinguish it from upstream.

Five patches were needed:

1. DeviceClass API version — resource.k8s.io/v1beta1 to resource.k8s.io/v1:

# apps/intel-gpu-driver/chart/templates/device-class.yaml
apiVersion: resource.k8s.io/v1
kind: DeviceClass
metadata:
  name: gpu.intel.com

2. ValidatingAdmissionPolicy — both the policy API version and the ResourceSlice API version it watches:

# apps/intel-gpu-driver/chart/templates/validating-admission-policy.yaml
apiVersion: admissionregistration.k8s.io/v1
kind: ValidatingAdmissionPolicy
spec:
  matchConstraints:
    resourceRules:
    - apiGroups:   ["resource.k8s.io"]
      apiVersions: ["v1"]
      resources:   ["resourceslices"]

3. Namespace PSA label — the DRA driver DaemonSet uses hostPath volumes for /var/lib/kubelet/plugins, /sys, and the CDI directory. Kubernetes Pod Security Admission blocks this by default. The namespace needs the privileged enforcement level:

# apps/intel-gpu-driver/chart/templates/resource-driver-namespace.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: intel-gpu-resource-driver
  labels:
    pod-security.kubernetes.io/enforce: privileged

4. CDI hostPath — the DaemonSet’s cdi volume mount pointed to /etc/cdi on the host. Changed to /var/cdi/dynamic to match the containerd config patch:

# In the DaemonSet template (resource-driver.yaml)
volumes:
- name: cdi
  hostPath:
    path: /var/cdi/dynamic    # was /etc/cdi
    type: DirectoryOrCreate

5. Image update — the upstream chart used intel/intel-gpu-resource-driver:v0.7.0 from Docker Hub. Updated to v0.9.1 from GitHub Container Registry, which is the version that supports resource.k8s.io/v1:

# apps/intel-gpu-driver/values.yaml
image:
  repository: ghcr.io/intel/intel-resource-drivers-for-kubernetes
  name: intel-gpu-resource-driver
  tag: "v0.9.1"

The ArgoCD Application points directly at the vendored chart path in the Git repo:

# apps/root/templates/intel-gpu-driver.yaml (abbreviated)
spec:
  sources:
    - repoURL: https://github.com/derio-net/frank.git
      path: apps/intel-gpu-driver/chart
      helm:
        releaseName: intel-gpu-driver
        valueFiles:
          - ../values.yaml
  syncPolicy:
    automated:
      prune: false
      selfHeal: true

Because the chart is vendored, ArgoCD syncs it like any other Git-tracked resource. When Intel releases an upstream chart with v1 support, we can re-vendor or switch back to the remote chart — but for now, this approach gives us full control and transparency over every API version in the templates.

Verifying It Works

After ArgoCD syncs the intel-gpu-driver app, three DaemonSet pods should be running (one per mini node):

$ kubectl get pods -n intel-gpu-resource-driver -o wide
NAME                                            READY   NODE
intel-gpu-resource-driver-kubelet-plugin-xxxxx   1/1    mini-1
intel-gpu-resource-driver-kubelet-plugin-yyyyy   1/1    mini-2
intel-gpu-resource-driver-kubelet-plugin-zzzzz   1/1    mini-3

Each pod publishes a ResourceSlice for its node’s GPU:

$ kubectl get resourceslice -o wide
NAME                       DRIVER         NODE
mini-1-gpu-intel-com-...   gpu.intel.com  mini-1
mini-2-gpu-intel-com-...   gpu.intel.com  mini-2
mini-3-gpu-intel-com-...   gpu.intel.com  mini-3

The DeviceClass should exist:

$ kubectl get deviceclass
NAME            AGE
gpu.intel.com   2d

To verify end-to-end, run a smoke-test pod that claims a GPU and lists the DRI devices:

apiVersion: v1
kind: Pod
metadata:
  name: gpu-smoke-test
spec:
  containers:
  - name: test
    image: ubuntu:24.04
    command: ["ls", "-la", "/dev/dri/"]
    resources:
      claims:
      - name: gpu
  resourceClaims:
  - name: gpu
    deviceClassName: gpu.intel.com
  restartPolicy: Never

The pod gets scheduled onto one of the mini nodes, the ResourceClaim binds, and the CDI spec injects the GPU devices:

$ kubectl logs gpu-smoke-test
crw-rw---- 1 root video 226,   0 Mar  4 ... /dev/dri/card0
crw-rw---- 1 root render 226, 128 Mar  4 ... /dev/dri/renderD128

Both card0 (display) and renderD128 (compute/render) are present. The GPU is accessible to the container through the DRA pipeline: ResourceSlice advertised the device, DeviceClass matched it, ResourceClaim requested it, the kubelet plugin injected it via CDI.

What We Have Now

At this point the cluster has:

  • Intel Arc iGPU exposed on mini-1/2/3 via DRA (ResourceSlice/ResourceClaim)
  • NVIDIA RTX 5070 detected and operational on gpu-1, GPU Operator deployed with automated sync
  • GPU-local Longhorn storage on gpu-1 for AI workloads

Both GPU paths are live. The DRA stack on the Intel side demonstrates the future of GPU scheduling in Kubernetes. The NVIDIA side took a hardware detour — an invisible card that turned out to need nothing more than a firm reseat — but the full software stack was ready and waiting when the hardware came online.

References

Next: GitOps Everything with ArgoCD

Persistent Storage with LonghornGitOps Everything with ArgoCD
